Magnetic HPL
Writable surface with magnetic properties for offices and educational spaces
Quick Specifications
Product Overview
Magnetic HPL is an innovative multifunctional high-pressure laminate that combines magnetic receptivity with a dry-erase writable surface, creating an all-in-one collaboration solution for modern workspaces and educational environments. Manufactured using a specialized three-layer construction: a magnetic steel substrate core (0.3-0.5mm thickness), phenolic resin-impregnated kraft paper layers for structural stability, and a premium melamine surface layer with dry-erase coating. The production process involves high-pressure lamination (100-120 kg/cm²) at controlled temperatures (140-160°C) to bond these layers into a unified panel. The magnetic core provides strong magnetic holding power capable of supporting 5-8 sheets of standard paper (80gsm) per neodymium magnet, or securely holding magnetic accessories, documents, and visual aids. The top surface features a smooth, non-porous dry-erase coating that accepts standard whiteboard markers and erases cleanly without ghosting or staining. The surface maintains excellent writability and erasability even after thousands of write-erase cycles. Available in classic white for maximum marker contrast, or light gray for reduced glare in bright environments. Panel thickness ranges from 3mm to 6mm depending on magnetic core thickness and structural requirements. The material is self-supporting for wall-mounted installations, or can be applied to backing panels for larger wall coverage. Meets international standards including EN 438 for laminate properties and ISO 21568 for magnetic whiteboards. Ideal for corporate meeting rooms, collaborative workspaces, educational classrooms, training centers, design studios, and any environment requiring flexible, interactive wall surfaces for brainstorming, teaching, and visual communication.
Technical Specifications
Physical Properties
| Thickness Range | 3mm - 6mm |
| Standard Sizes | 1220×2440mm, 1530×3660mm |
| Density | ≥1.40 g/cm³ |
| Magnetic Layer | Embedded ferrous particles |
| Surface Finish | Gloss white (writable) |
| Core Material | Magnetic steel (0.3-0.5mm) |
Magnetic Performance
| Magnetic Strength | Holds 5-8 sheets A4 paper |
| Magnet Compatibility | Standard office magnets |
| Magnetic Coverage | 100% surface area |
| Holding Power | ≥50g per magnet |
Writing Surface
| Dry-Erase Compatible | Yes (standard markers) |
| Erasability | Excellent (no ghosting) |
| Stain Resistance | High (permanent marker removable) |
| Gloss Level | 60-80 GU |
| Write-Erase Cycles | >10,000 cycles |
Standards & Certifications
| EN 438 | HPL Standard |
| ISO 21568 | Whiteboard Standard |
| ISO 9001 | Quality Certified |
| Fire Rating | Class B (GB 8624) |
Key Benefits
Magnetic
Strong magnetic attraction, holds multiple documents
Writable
Dry-erase marker compatible, easy erasing
Easy to Clean
Stain-resistant, wipes clean instantly
Durable Surface
Scratch-resistant, maintains appearance
Dual Function
Write and display simultaneously
Ghost-Free
No marker residue or ghosting
Impact Resistant
Withstands daily office use
Fire Rated
Class B fire safety compliance
Applications
Corporate Meeting Rooms and Collaborative Workspaces
Heavy UseEssential for modern corporate offices embracing collaborative work methodologies and agile project management. Magnetic HPL transforms meeting room walls into interactive brainstorming surfaces where teams can write ideas with dry-erase markers while simultaneously posting sticky notes, project cards, and printed materials using magnets. The dual functionality eliminates the need for separate whiteboards and bulletin boards, maximizing usable wall space in conference rooms. Teams can create Kanban boards, sprint planning layouts, and visual project timelines by combining written content with magnetic cards and accessories. The smooth dry-erase surface accepts all standard whiteboard markers and erases cleanly without ghosting, maintaining a professional appearance for client presentations. Magnetic holding power is sufficient to support multiple layers of documents, allowing teams to build complex information hierarchies on the wall surface. Popular in design thinking workshops where participants need to rapidly iterate and reorganize ideas. The material's durability withstands intensive daily use in high-traffic meeting spaces. Easy to clean with standard whiteboard cleaners or damp cloths. Installation as full-wall coverage creates expansive collaboration surfaces that encourage creative thinking and team engagement. Cost-effective compared to traditional porcelain whiteboards while offering superior functionality through magnetic capability.
Educational Classrooms and Training Centers
Heavy UseRevolutionizes classroom teaching by providing teachers with a versatile instructional surface that combines traditional whiteboard functionality with magnetic display capabilities. Teachers can write lesson content with markers while simultaneously displaying magnetic letters, numbers, geometric shapes, and educational manipulatives. Elementary classrooms benefit from the ability to create interactive learning stations where students can arrange magnetic word cards, math tiles, and visual aids. Science teachers use the magnetic surface to display periodic table elements, anatomical diagrams, and experimental procedure cards that can be easily rearranged. Language teachers create interactive grammar exercises by arranging magnetic word cards into sentences. The large writable surface area (when installed as full-wall coverage) provides ample space for complex mathematical equations, detailed diagrams, and collaborative student work. The smooth surface ensures clear, legible handwriting that is visible from the back of the classroom. Erases cleanly without residue, maintaining a professional teaching environment. Durable enough to withstand daily use by multiple classes and student interaction. Training centers use Magnetic HPL for corporate training sessions, allowing instructors to create dynamic, interactive presentations that combine written content with visual materials. The material's longevity (10,000+ write-erase cycles) ensures years of reliable service in educational settings.
Design Studios and Creative Agencies
Medium UseIndispensable for design studios, advertising agencies, and creative teams who need flexible wall surfaces for mood boards, design iterations, and client presentations. Designers can sketch concepts directly on the surface with markers while pinning inspiration images, color swatches, and material samples using magnets. The combination of writable and magnetic functionality supports the iterative design process where ideas evolve through multiple revisions. Creative teams use the surface for storyboarding, where scene sketches can be combined with magnetic frame cards and narrative notes. Advertising agencies create campaign planning walls where creative concepts, target audience profiles, and media strategies are visualized using a mix of written content and magnetic visual elements. The white or light gray surface provides a neutral backdrop that doesn't compete with the colors and designs being displayed. Easy to reconfigure as projects evolve—simply erase and rewrite, or rearrange magnetic elements without leaving marks or damage. The magnetic holding power is sufficient to support fabric swatches, paper samples, and lightweight product prototypes. Interior designers use Magnetic HPL in client presentation rooms to build material palettes and design schemes that can be adjusted in real-time during client consultations. The professional appearance and easy maintenance make it suitable for client-facing spaces.
Healthcare Facilities and Hospital Administration
Heavy UseValuable in hospital administrative areas, nursing stations, and medical training rooms where visual communication and information display are critical for patient care coordination. Nursing stations use Magnetic HPL to display patient assignment boards where room numbers and patient names can be written with markers while color-coded magnetic status indicators show patient conditions, treatment schedules, and care priorities. The easy-update format allows nursing staff to quickly modify information as patient situations change throughout shifts. Hospital administrative offices use the surface for staff scheduling, displaying shift rotations and on-call assignments with magnetic name tags that can be easily moved. Medical training rooms benefit from the combination of writable surface for teaching medical procedures and magnetic capability for displaying anatomical charts, treatment protocols, and medical device diagrams. The smooth, non-porous surface meets healthcare hygiene standards and can be cleaned with medical-grade disinfectants. Emergency departments use Magnetic HPL for patient tracking boards, displaying triage status and treatment room assignments. The material's durability withstands the demanding 24/7 healthcare environment. The visual clarity of the white surface ensures information is easily readable under hospital lighting conditions, reducing communication errors in fast-paced medical settings.
